Acer tech specs
- Acer Travelmate 290 series
- Acer Travelmate 291 LMi
- CPU : Intel Pentium M, 1,4 GHz
- Chipset : 855 GM
- RAM : 512 MB DDR
- CRT : 15" XGA TFT
- Intel 82852/82855 GM/GME graphics controller
- HD : 60 GB ATA/100
- DVD
- Wifi : 2200 BG
IALMRNT5 driver problem
Busqueda : Intel
Solució : Intel
82852/82855 Graphics Controller Family
82852/82855 Graphics Controller Family - software&drivers, Issues&solutions, FAQ's, ...
Piano
Escala del piano, 7 octavas + 1/3, 88 tecles (52 blanques, 36 negres)
El Acer de'n Josep
Acer TravelMate P238-M-P308
HW :
- RAM : Kingston 4 GB, 1Rx8, PCL3, DIMM
- HDD : Kingston 128 GB SSD (M.2 Slot, SATA)
- GPU : Intel HD Graphics 520
- screen resolution : 1366 x 768 (HD)
Problema 20260414
Default boot device missing or boot failed - the system cannot find a bootable drive
- try BIOS
- enter the BIOS using F2 after "Acer" logo is displayed
- go to "Main" tab
- make sure "Network Boot" is disabled and "F12 boot menu" is enabled
- toggle "UEFI" and "Legacy" and try to boot - leave "UEFI" at end
- under "Boot" tab, set "USB HDD" as first option
- use Windows Media Creation Tool -
download
- boot "Windows installation media" and select "Repair"
- when finished, choose "Troubleshoot > Command Prompt"
- "diskpart" + "list disk" + "select disk 0" + "list partition"
- boot "Mint Live USB" ("Integral" 8 GB USB)
- dmesg -i /dev/sda
- Gparted
- Discs
- "ping 8.8.8.8" despres de escollit la wifi (baix a la dreta)
- "sudo gdisk -l /dev/sda"
- repara repositoris :
sudo rm -rf /var/lib/apt/lists/* sudo rm -f /etc/apt/sources.list.d/* sudo nano /etc/apt/sources.list # Esborra tot el que hi hagi i enganxa exactament aquestes dues línies: deb http://archive.ubuntu.com/ubuntu/ jammy main universe deb http://archive.ubuntu.com/ubuntu/ jammy-updates main universe sudo apt update --allow-insecure-repositories sudo apt install smartmontools testdisk --allow-unauthenticated -y
- verifiquem SSD :
sudo smartctl -a /dev/sda Tipus de taula: tria [ EFI GPT ] si és un ordinador dels darrers 10 anys o [ Intel ] si és més antic.
Botons i LEDs al frontal
3 LEDs top left :
- Hard Disk / SSD activity (Cylinder icon)
- Power indicator (Light Bulb icon)
- Battery indicator (Battery icon)
Hard reset : hold the power button down for a full 15 seconds until the light goes out completely.
Then, turn it back on. This clears the power controller (EC) and often restores the LED to full brightness.
Com obrir-lo per accedir al disc SSD i la bateria
- unscrew 5+3+4 screws
- inserta una paleta de plàstic a la cantonada i fes que faci la volta
Battery reset pinhole
Small hole in the top of the back.
- resets the power management circuits
- drains remaining charge from the motherboard
While the laptop is off and unplugged, insert a paperclip and hold it down for 10–15 seconds.
Let the laptop sit for 5 minutes, then plug in the charger and try to power it on.
Intentem llegir el SSD vell
sebas@minie:~$ dmesg
[ 2604.954411] sd 1:0:0:0: [sdb] tag#12 CDB: Read(16) 88 00 00 00 00 00 00 00 00 00 00 00 00 08 00 00
[ 2604.954414] I/O error, dev sdb, sector 0 op 0x0:(READ) flags 0x0 phys_seg 1 prio class 2
[ 2604.954422] Buffer I/O error on dev sdb, logical block 0, async page read
[ 2604.994391] sd 1:0:0:0: [sdb] tag#14 FAILED Result: hostbyte=DID_ERROR driverbyte=DRIVER_OK cmd_age=0s
[ 2604.994399] sd 1:0:0:0: [sdb] tag#14 Sense Key : Illegal Request [current]
[ 2604.994404] sd 1:0:0:0: [sdb] tag#14 Add. Sense: Logical block address out of range
[ 2604.994409] sd 1:0:0:0: [sdb] tag#14 CDB: Read(16) 88 00 00 00 00 00 00 00 00 18 00 00 00 08 00 00
[ 2604.994412] I/O error, dev sdb, sector 24 op 0x0:(READ) flags 0x0 phys_seg 1 prio class 2
[ 2604.994420] Buffer I/O error on dev sdb, logical block 3, async page read
[ 2605.075413] sdb: unable to read partition table
[ 2605.075541] sd 1:0:0:0: [sdb] Attached SCSI disk
A veure :
sebas@minie:~$ sudo smartctl -a /dev/sdb
smartctl 7.2 2020-12-30 r5155 [x86_64-linux-6.8.0-117-generic] (local build)
Copyright (C) 2002-20, Bruce Allen, Christian Franke, www.smartmontools.org
/dev/sdb: Unknown USB bridge [0x152d:0x0586 (0x4205)]
Please specify device type with the -d option.
Use smartctl -h to get a usage summary
Provem
sebas@minie:~$ sudo smartctl -d sat -a /dev/sdb
smartctl 7.2 2020-12-30 r5155 [x86_64-linux-6.8.0-117-generic] (local build)
Copyright (C) 2002-20, Bruce Allen, Christian Franke, www.smartmontools.org
=== START OF INFORMATION SECTION ===
Device Model: PS3111
Serial Number: [No Information Found]
Firmware Version: SBRM02.0
User Capacity: 20.972.032 bytes [20,9 MB]
Sector Size: 512 bytes logical/physical
Device is: Not in smartctl database [for details use: -P showall]
ATA Version is: ATA/ATAPI-7 T13/1532D revision 4a
Local Time is: Fri May 29 19:14:01 2026 CEST
SMART support is: Unavailable - device lacks SMART capability.
A mandatory SMART command failed: exiting. To continue, add one or more '-T permissive' options.
Resposta
Això és un diagnòstic definitiu.
El fet que smartctl reporti una capacitat de només 20 MB (quan un SSD M.2 hauria de tenir centenars de GB)
és el que anomenem en informàtica un "SSD en mode ROM" o "Fail-safe mode".
El model que apareix, PS3111, correspon al controlador Phison S11.
Aquest controlador és famós per un error conegut:
quan detecta un error intern greu en les cel·les de memòria NAND (o en el seu propi firmware),
es bloqueja i entra en un mode de recuperació bàsic.
Per això et diu que té 20 MB: no està llegint la teva memòria real, està llegint una petita zona de "seguretat" del propi xip controlador.
Dades perdudes: En aquest mode, l'SSD no té accés a la teva taula de particions ni a les teves dades.
Les dades encara hi són físicament, però el firmware del disc ha bloquejat l'accés per evitar més danys.
Si les dades no són importants:
El disc està espatllat físicament.
Aquests discs amb controlador Phison S11 que entren en mode 20 MB gairebé mai es poden reparar de forma domèstica.
Intentem formatejar-lo :
sebas@minie:~$ sudo wipefs -a /dev/sdb ; eliminarem qualsevol rastre de la taula de particions corrupta que té ara mateix
sebas@minie:~$ sudo parted /dev/sdb mklabel gpt
Warning: Error fsyncing/closing /dev/sdb: Remote I/O error
Retry/Ignore? r
L'error Remote I/O (Entrada/Sortida remota) en un disc connectat per USB sol ser el resultat
que la placa controladora del SSD ha perdut la capacitat de comunicar-se amb les memòries NAND.
En aquest punt, el disc s'ha convertit en una peça de maquinari inoperativa.
Que comprem ?
- SSD - SSD M.2 SATA 2280
compte "SATA"
compte "B+M key"
Amazon 31 € - RAM - 4GB DDR3L 1600MHz SO-DIMM PC3L-12800S CL11
Compte amb la "L" de DDR3L i PC3L : 1,35 volts en lloc de 1,5 volts
Comprar una per fer parella amb la que tenim es complicat.
Comprar dues ja no es tan barat
M.2 SSD 128 GB SATA III
sebas@minie:~$ dmesg
[22704.790908] usb 2-2: new SuperSpeed Plus Gen 2x1 USB device number 3 using xhci_hcd
[22704.803324] usb 2-2: New USB device found, idVendor=152d, idProduct=0586, bcdDevice=42.05
[22704.803332] usb 2-2: New USB device strings: Mfr=1, Product=2, SerialNumber=3
[22704.803337] usb 2-2: Product: External
[22704.803341] usb 2-2: Manufacturer: JMicron
[22704.803345] usb 2-2: SerialNumber: DD0000000000001E
[22704.805185] scsi host1: uas
[22704.805544] scsi 1:0:0:0: Direct-Access JMicron 4205 PQ: 0 ANSI: 6
[22704.807047] sd 1:0:0:0: Attached scsi generic sg1 type 0
[22704.807316] sd 1:0:0:0: [sdb] 250069680 512-byte logical blocks: (128 GB/119 GiB)
[22704.807320] sd 1:0:0:0: [sdb] 4096-byte physical blocks
[22704.807396] sd 1:0:0:0: [sdb] Write Protect is off
[22704.807400] sd 1:0:0:0: [sdb] Mode Sense: 53 00 00 08
[22704.807576] sd 1:0:0:0: [sdb] Write cache: enabled, read cache: enabled, doesn't support DPO or FUA
[22704.832945] sd 1:0:0:0: [sdb] Preferred minimum I/O size 4096 bytes
[22704.832951] sd 1:0:0:0: [sdb] Optimal transfer size 33553920 bytes not a multiple of preferred minimum block size (4096 bytes)
[22704.834104] sd 1:0:0:0: [sdb] Attached SCSI disk
sebas@minie:~$
Instalem MINT
- posem SSD al Acer
- posem USB "Live Mint" al Acer i botem
- "Start Linux Mint 21.2 Cinnamon 64-bit"
- al desktop, fem click a "Install Linux Mint"
- pwd "Secure Boot" [/]
- nom equip "AcerP238"
- Perform MOK Management
- Continue boot (*)
- Enroll MOK
- Enroll key from disk
- Enroll hash from disk
- got loop : "Acer" logo + "Rest System"
- boot "Live USB" +
mint@mint:~$ sudo efibootmgr -v BootCurrent: 001 Timeout: 0 seconds BootOrder: 2001,0002,2002,2003 Boot0000* ubuntu Boot0001* USB HDD: USB Flash Memory Boot0002* Command Linpus lite Boot0003* Unknown Device: Boot2001* EFI USB Device Boot2002* EFI DVD/CDROM Boot2003* EFI Network
- set boot order properly
sudo efibootmgr -o 0000,2001,0002,2003
Comprovem :
mint@mint:~$ sudo efibootmgr -v
BootCurrent: 001
Timeout: 0 seconds
BootOrder: 0000,2001,0002,2003
Boot0000* ubuntu
Boot0001* USB HDD: USB Flash Memory
Boot0002* Command Linpus lite
Boot0003* Unknown Device:
Boot2001* EFI USB Device
Boot2002* EFI DVD/CDROM
Boot2003* EFI Network
- go to "Security" tab and set ""Supervisor Password" as "1234"
- goto "Boot" tab and set "Secure Boot" to "Disabled"
- use F10 to save and restart
- web browser : Firefox
- full de calcul : LibreOffice Calc
- editor de documents : LibreOffice Writer
|
|
|
